Product Details:
|
| Keywords: | Outdoor Electronic Advert | Application: | Digital Signage/Outdoor High Brightness Display |
|---|---|---|---|
| Contrast Ratio: | 4000:1 | Operating Temperature: | 0 ℃~40℃ |
| Brightness: | 2500cd/m2 | Response Time: | 12ms |
| Resolution: | 1920X1080 | Power Supply: | AC 110 ~ 240V, 50/60 Hz |
| Active Area: | 1073.78 (H) X 604 (V) Mm | Display Mode: | Normally Black |
| Lifetime: | 60000 Hours | Backlight: | LED Backlight |
| Display Type: | IPS, TFT | Color: | Customized |
| Highlight: | 55 Inch Interactive Digital Kiosk,60000 Hours Interactive Digital Kiosk,Rohs Interactive Digital Kiosk |
||
At the beginning people went to change the advertisement in each digital signage(device, hereinafter) one by one. Assuming there are 800 devices, it will be time-and-labor consuming. In order to solve this problem, one embedded solution came out. It connected the devices together to a server by wifi – network lcd advertising display. Actually it was not good enough, especially when the wifi signal is weak or there are too many devices.
With the improvement and popularization of Android OS, the light of real network digital signage appeared. The Android digital signage(device, hereinafter) is a perfect solution for remotely management. First Connect the devices to the internet either by wifi, LAN or 3G. Second open your pc and deliver the advertisement to the devices easily, no matter where the devices they locate. The stable Android OS makes the device work 7/24 hours safe and sound.
What’s more the Android system provides an access to users which make it possible to customize personalized applications.
Thanks to technology progress, the outdoor lcd display becomes more and more reliable. By integrated the digital signage solution and outdoor design, it extends the lcd digital signage from indoor to outdoor, a vast market demand.
Main features:
**Smart forced air cooling system or air-conditioner system to ensure stable and reliable performance.
**IP65(customizable) design outdoor digital signage, waterproof, vandal proof, sun readable.
**High brightness up to from 1500 cd/m2 to 4500 cd/m2, or even higher.
**Suitable for various kinds of outdoor environment, such as snow, desert, shore etc, and support operation temperature from -40 Celsius to +55 Celsius.
1. Auto play back advertisement after power on, no need operation manually.
2. Support split screen, one screen window is divided into several sections for different usages.
3. Scrolling message, the pre-set message can be displayed.
4. Play HD 1080P videos and pictures.
5. Remotely manage devices in different locations by internet(*).
Specifications:
| Parameters | ||
| Panel Data | Panel Brand | For Samsung/LG |
| Size | 65 inch | |
| Native Resolution | 1920x1080 | |
| Aspect Ratio | 16:9 | |
| Surface | Antiglare, hard coating | |
| Active Area | 1428.5(H) X 803.5(V) mm | |
| Dot Pitch | 0.248(H) X 0.744(V) mm | |
| Brightness | 2500cd/m2(customizable) | |
| Contrast Ratio | 4000:1 | |
| Display Colors | 16.7M | |
| Response Time | 6ms | |
| View Angle | 89/89/89/89(L/R/U/D) | |
| Frequency | 60Hz | |
| Network Data(*) | Android | ARM Cortex Quad Core 1.8G Hz |
| RAM | 2GB | |
| ROM | 8GB | |
| OS | Android 4.1/4.2 or above | |
| Video decoding | HD H.264 2160p video decoding Multi-format FHD(1920x1080P) video decoding |
|
| Audio | Integrated HI-FI 100dB Audio Codec | |
| Picture format | JPG, PNG, JPEG... | |
| TXT | YES | |
| Main I/O | HDMI x1, VGA x1, SD/TF slot x1, USB x2, RJ45 x1 | |
| WiFi | Built-in Wifi(802.11b/g/n) | |
| General Information | Image Resolution | 5000 x 5000 px Max |
| Video Resolution | 1920 x 1080p Max | |
| Color | Silver, Black, White or Customized | |
| Material | Fine Aluminum + AR safe glass | |
| Speaker | 10W x2 | |
| Remote Control | IR Remote Control | |
| Menu Language | English, Germany, Russian, French and Spanish etc | |
| Power Supply | AC 110 ~ 240V | |
| Operation Temperature | -40 ℃~+55℃ | |
| Operation Humidity | 5% ~ 100% | |
| Operating Altitude | 0~3,000 meters | |
| Storage Temperature | -50 ℃~60℃ | |
| Storage Humidity | 0 ~ 90% | |
| Installation | Free Standing | |
Remarks: 1. (*) means the functions are for network version.
With a powerful brightness of 2,500 cd/m2 and wide viewing angles, 49 inch outdoor signage display delivers content clearly and catches the attention of viewers no matter where they are, making it the ultimate display for outdoor visibility, it can catch customers' eyes, and win more orders.
Freestanding 55 inch outdoor digital signage's electrical circuit breaker and surge suppressor are integrated inside ensuring absolute protection from overcurrent short circuits, and unwanted voltages. This helps prevent equipments damage and safety hazards in the future.
Play and manage your content right out-of-the-box with our embedded all in one digital signage solution. Backed by the powerful digital signage operating system, you can easily manage content and ensure seamless content transitions and playback. All without the need for an external signage player or PC.
IDP outdoor smart signage solutions are specially engineered from the ground up to weather the elements with high-brightness, protective glass and IP56 certification. You can display your messages in heat, cold, rain, snow and dust.
