Product Details:
|
| Size: | 24inch | Response Time: | 5ms |
|---|---|---|---|
| Video Decoding: | HD H.264 2160p Video Decoding Multi-format FHD(1920x1080P) Video Decoding | Picture Format: | JPG, PNG, JPEG... |
| Speaker: | 10W X2 | Storage Humidity: | 0 ~ 90% |
| Installation: | Wall Mount | TXT: | YES |
| Android: | ARM Cortex-A17 | OS: | Android |
| High Light: | 24 Inch Digital Signage Advertising Network,Android 5.1 24 Inch Digital Signage,Digital Signage Advertising Network H.264 2160p |
||
24 inch Android Digital Signage with Network H.264 2160p Video Decoding
At the beginning people went to change the advertisement in each digital signage(device, hereinafter) one by one. Assuming there are 800 devices, it will be time-and-labor consuming. In order to solve this problem, one embedded solution came out. It connected the devices together to a server by wifi – network lcd advertising display. Actually it was not good enough, especially when the wifi signal is weak or there are too many devices.
1. With the improvement and popularization of Android OS, the light of real network digital signage appeared.
The Android digital signage(device, hereinafter) is a perfect solution for remotely management. First Connect the devices to the internet either by wifi, LAN or 3G. Second open your pc and deliver the advertisement to the devices easily, no matter where the devices locate. The stable Android OS makes the device work 7/24 hours safe and sound.
2. Window display, Outstanding Visibility
Visible with Polarized Sunglasses
IDP's Window display enables clear visibility even when the viewer is wearing polarized sunglasses.
3. True Color Calibration, window display
The high-brightness window display has been calibrated to the ultra-high color standard at the factory. This color setting produces a natural looking image which has a correlated color temperature to that of daylight.
Main Features:
1. Auto play back advertisement after power on, no need operation manually.
2. Support split screen, one screen window is divided into several sections for different usages.
3. Scrolling message, the pre-set message can be displayed.
4. Play HD 1080P videos and pictures.
5. Remotely manage devices in different locations by internet(*).
6. Support online video dreaming(*).
7. Easy upgraded if the advertisement business layout changes(*).
8. Support more apps with the upgrade of Android OS(*).
9. Optional function:PCAP touch, 4G, printer, camera, high brightness, customized Android applications(*)
10. OEM/ODM design: digital signage enclosure, functions etc.
More detail:
| Parameters | ||
| Panel Data | Panel Brand | For Samsung/LG |
| Size | 24 inch | |
| Native Resolution | 1920x1080 | |
| Aspect Ratio | 16:10 | |
| Surface | Antiglare, hard coating | |
| Active Area | 518.4(H) x 324.0(V) mm | |
| Dot Pitch | 0.090(H) x 0.270(V) mm | |
| Brightness | 400cd/m2 | |
| Contrast Ratio | 1000:1 | |
| Display Colors | 16.7M(8-bit) | |
| Response Time | 5ms | |
| View Angle | 89/89/89/89(L/R/U/D) | |
| Frequency | 60Hz | |
| Network Data(*) | Android | ARM Cortex-A17 |
| RAM | 2GB(4GB for optional) | |
| Land flash | 8GB(option, up to 32GB) | |
| OS | Android | |
| Video decoding | HD H.264 2160p video decoding Multi-format FHD(1920x1080P) video decoding |
|
| Audio | Integrated HI-FI 100dB Audio Codec | |
| Picture format | JPG, PNG, JPEG... | |
| TXT | YES | |
| Main I/O | HDMI x1, VGA x1, SD/TF slot x1, USB x2, RJ45 x1 | |
| WiFi | Built-in Wifi(802.11b/g/n) | |
| General Information | Image Resolution | 5000 x 5000 px Max |
| Video Resolution | 1920 x 1080p Max | |
| Color | Silver, Black, White or Customized | |
| Material | Fine Aluminum + Tempered Glass | |
| Speaker | 10W x2 | |
| Remote Control | IR Remote Control | |
| Menu Language | English, Germany, Russian, French and Spanish etc | |
| Power Supply | AC 110 ~ 240V | |
| Operation Temperature | 0 ℃~40℃ | |
| Operation Humidity | 20% ~ 80% | |
| Operating Altitude | 0~3,000 meters | |
| Storage Temperature | -20 ℃~60℃ | |
| Storage Humidity | 0 ~ 90% | |
| Installation | Wall mount | |
Applications:
*The details are subject to upgraded without notice in advance.
